Western 500 - Outrigger and Remixer Controls

10
Hydraulic Jackstand Levers
Control the extending/retracting
of the machine support stands.
Remixer Forward/Reverse Lever
Shifts the remixer motor between
Forward, Reverse, or Neutral.
This control lever is detented to
remain in position selected by the
operator. This lever is normally
in the Forward position so that
concrete will be drawn from the
walls of the hopper and pushed
into the material cylinders.
General Technical Description
Outrigger Controls
