LEONARDO DATALOGGER
User manual
EN
1
REV 2.0 05-12-2018
LEONARDO DATALOGGER
General features:
Leonardo datalogger is a monitoring system for Leonardo series inverter.
The datalogger connects to the Internet through a wired Ethernet connection
and it sends data to a remote server (WCloud), making them available for
viewing on mobile devices such as smartphones and tablets, or workstations,
such as PC or Laptop.
Data can be visualized using specific APP application for mobile devices (for iOS
or Android system) or using a web portal available via PC or laptop browser.
The inverter data are acquired via RS485 serial connection and connection of
RJ-45 type.
• Monitoring System for Leonardo
inverter series
• Connection via Ethernet cable
• RS485 connection for inverter
• RS485 connection for charge
controller
• Back-up data
• LED indicator
• Web monitoring with remote
server
• APP for Tablet e Smartphone
• USB power supply
