Westinghouse Portable Power | 25
iPro4200 EXPLODED VIEW PART NO.
No. Part. Description
1 180601 Engine Assy
2 150557 Fuel Tank Assy
3 150556 Fuel Vale
4 150558 Fuel Cap
5 150529 Fuel Strainer
6 100614 Frame
7 100615 Hose Clamp
8 130558 Choke Cable
9 100578 Damper
10 100616 Bracket
11 100617 Bracket
12 100618 Bracket
13 130559 Control Panel
14 120548 Seal
15 120549 Duct
16 120551 Inlet Grate
17 120550 Outlet cover
18 130560 M8 X 110
19 130561 Control Panel
20 150559 Vent Hose
21 120539 M6 X 12
22 100619 M6 X 16
23 100620 Hose Clamp
24 120552 Clamp
25 100565 Rubber Boot
26 120553 Ground Strap
27 100621 Washer
28 100622 Rubber Hose
29 150547 M6 Washer
30 100623 BOLT M8X40
31 100624 Hose Clamp
32 100625 Isolator
33 100626 Bracket
34 100627 Bracket
35 100628 Rubber Hose
36 150520 Carbon Canister
37 100629 Bracket
38 100630 M8 X 30
39 150532 M6 X 16
40 100631 M6 X 25
41 180524 M8 Nut
42 100632 NUT M8
43 100633 M6 X 12
44 100634 M4 X 10
45 130500 DC Regulator
46 100635 Hose Clamp
