53
Machine control board, Software
704 67 020 00 _ 111
OPERATING INSTRUCTIONSGF Robimat XL / XM
[PROTOCOL (1)]
[EVA-DTS] (default) Data transfer protocol between vending machine controller and payment system.
[DEX/UCS] This protocol is only required if a display with DEX/UCS interface is connected.
[EVA-DTS VERSION]
[6.0 (5.x, 4.x)] Programming EVA-DTS Version.
[6.1 or newer] This version contains additional information. It is required for future applications.
[IRDA Adapter] IRDA = Infrared-interface
[Cable] This setting is necessary if, for example, a DEX/UCS interface can be connected to the display
and EVA-DTS data is to be read out from it.
[IRDA] This is the standard setting and means that EVA-DTS data can be read out via the integrated
IRDA interface.
[EVA-DTS SEL.No.] You can determine how the selection numbers are reported to MDB here and in EVA-DTS.
This setting has no eect on machines with selection numbers starting with 1.
[starts with] 1 (default) The lowest selection number in the machine is 1.
[starts with] 10 The number being transmitted, is the one shown as the selection number on the display.
CHECK
←L SEL. M→ :E
M
7
INSTALLING MODE
←L SEL. M→ :E
INSTALLING MODE
> MACHINE
PROTOCOL(1)
EVA-DTS
EVA/DTS VERSION
6.0(5.0x,4.x)
IRDA max.RATE
19200
INSTALLING MODE
> READOUT
USE VERBOSE CGW
no
DTS data select
PA2 on
INTERVAL EV.CTL.
auto
E L
E L
E
L
E L
E L
E L
2xM
INTERVAL DT.CTL.
auto
IRDA Adapter
integrated(IRDA)
E L
E L
EVA/DTS SEL. No.
starts with 1
E L
E L
EXT. SERIAL 5.2
HMI
EXT.READOUT PROT
DDCMP
