Machine control board, Software
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
[IRDA max. RATE] IRDA = Infrared-interface
[19,200] (default) Infrared-interface (IRDA) data transfer rate is between 19,200 Bit/s and 57,600 Bit/s. The
display installed as standard has a data transfer rate of 19,200 Bit/s.
[CGW REPORTS]
[no] (default) Is only necessary if online modules compatible to "Verbose" are to be installed. Siela uses
the FTL mode for data transfer which includes additional information to NAMA standard
Verbose.
[INTERVAL DT. CTL.] only for EVA-DTS 6.1 Standard
[auto] Once the statistics have been downloaded, they are deleted when the next vend is made (as
before).
[save] The statistics are not deleted after downloading. Deletion must be started via IR.
[INTERVAL EV.CTL.] only for EVA-DTS 6.1 Standard
[auto] The errors are deleted once they have been read out and when the next vend is made (as
before).
[save] The errors are not deleted after having been read out; deletion must be started via IR.
[DTS data select] Fields can be switched on and o individually. The denition of the elds is described in the
EVA-DTS specication.
Fields: PA2 - PA3 - PA4 - PA5 - PA6 - PA7 - PA8
[on] Transfer is enabled.
[o] Transfer of corresponding elds (e.g. PA8) is inhibited.
[EXT. SERIAL 5.2] Programme machine data read out function.
[HMI] Read out using HMI-protocol
[READ OUT] Read out using downloading devices.
[EXT.READOUT PROT]
External readout possibility using corresponding equipment.
[DDCMP] Readout using DDCMP
