WD-151E - WD-421E Rev. 00 (202310)
Installation instructions touch
28
“D” indicating alternative opening for detergent
Plugged hole for measuring cell
Drying agent dosage
The connection for drying agent (4) is located next to the booster heaters.
Drying agent dosage outlet
A = Lower booster heater
