WD-151E - WD-421E Rev. 00 (202310)
Operating instructions touch
38
Curtain placement
The curtains in the machine must hang in accordance the image depending on
the feed direction.
The number of curtains is dependent on the size of the machine.
WD-151E WD-211E WD-241E WD-331E WD-421E
5 pcs. 6 pcs. 6 pcs. 6 pcs. 6 pcs.
L - R
R - L
