Wexiodisk WD-151E touch - Connection: Electrically Heated Machine; Connection: Steam-Heated Machine

WD-151E - WD-421E Rev. 00 (202310)
Technical specifications touch
66
* Other voltages on request.
** With different options.
* Other pressures available on request.
** Other voltages on request.
*** With different options.
CONNECTION, ELECTRICALLY HEATED MACHINE
Total connected power (kW), WD-151E 32.6
Total connected power (kW), WD-211E - WD-241E 40.1
Total connected power (kW), WD-331E 47.6
Total connected power (kW), WD-421E 58.1
Main fuse 400V 3N~ (A) *, WD-151E 50 / 63 **/ 80**
Main fuse 400V 3N~ (A) *, WD-211E - WD-241E 63 / 80 **/ 100**
Main fuse 400V 3N~ (A) *, WD-331E 80 / 80 **/ 100**
Main fuse 400V 3N~ (A) *, WD-421E 100 / 100 **/ 125**
Max. connection area 400V 3N~ (L1-L3, N, PE) (TN-S) Cu (mm²) 35
Main fuse 230V 3~ (A) *, WD-151E 100 / 125 **/ 160**
Main fuse 230V 3~ (A) *, WD-211E - WD-241E 125 / 125 **/ 160**
Main fuse 230V 3~ (A) *, WD-331E 160 / 160 **/ 200**
Main fuse 230V 3~ (A) *, WD-421E 160 / 200 **/ 200**
Max. connection area 230V 3~ (L1-L3, PE) (TN-S) Cu (mm²) 70
Maximum short-circuit current Icu (kA) 10
CONNECTION, STEAM-HEATED MACHINE 150-250 kPa *
Total connected power (kW), WD-151E 1.8
Total connected power (kW), WD-211E - WD-241E 3.4
Total connected power (kW), WD-331E 4.8
Total connected power (kW), WD-421E 6.0
Main fuse 400-415V 3N~ (A) **, WD-151E 16 / 16***
Main fuse 400-415V 3N~ (A) **, WD-211E - WD-241E 20 / 20***
Main fuse 400-415V 3N~ (A) **, WD-331E 20 / 20 *** / 25 ***
Main fuse 400-415V 3N~ (A) **, WD-421E 20 / 25 *** / 35 ***
Max. connection area 400V 3N~ (L1-L3, N, PE) (TN-S) Cu (mm²),
WD-151E - WD-241E
25
Max. connection area 400V 3N~ (L1-L3, N, PE) (TN-S) Cu (mm²),
WD-331E - WD-421E
35
Maximum short-circuit current Icu (kA) 10
Steam (internal thread), WD-151E - WD-241E R¾"
Steam (internal thread), WD-331E - WD-421E R1"
Condensing water (internal thread) R½"
