Operating Instruction
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating or adjusting this product. Please
keep this manual for future reference.
1. Features

HDMI 2.0 version (Support 4K@60Hz YUV4:4:4)

Bandwidth upto 18Gbps

HDCP1.4/2.2 compliant

Support HDR10,HLG,Dolby vision

4xHDMI Input, 4xHDMI output with 4xSPDIF coaxial Audio and 4xAnalog Audio

Any one of the 4 Ultra HD sources to any one of the 4 Ultra HD displays

Support IR control for long distance;RS232 control,Panel Button control,TCP/IP
control and Web GUI Control

Support PCM2.0,Dolby True HD and DTS-HD master audio, LPCM7.1, audio
sampling rate up to 192KHZ.

Support analog and S/PDIF audio extraction

Support EDID management and EDID study

Support firmware updating through USB port
2. Package Contents
1). 1x HDMI Matrix
2). 1x 12V/2A DC power supply
3). 1x Remote control
4). 1x IR Ext RX Cable
5). 5x Phoenix plugs for RS232 cable termination
6). 1x CD for control software & user manual
3. Specifications
Operating Temperature
0℃to+40℃(+32℉to+104℉)
Operating Humidity
5 to 90%RH(No Condensation)
Max resolution
4K@ 60hz YUV4:4:4
HDCP Compliant
HDCP2.2 and HDCP1.4
Output Video
HDMI2.0 and HDMI 1.4
Audio Format Supported
PCM2.0,Dolby True HD and DTS-HD master audio, LPCM7.1
RS-232 serial port
3PIN terminal block connectors
Ethernet port (IP control)
RJ45, female
IR Ext port
1x3.5mm stereo jack
USB port
Micro 5P female
Bandwidth
18 Gbps
Default IP
192.168.1.168
Rack-Mountable
Rack ears included
Dimensions(WxHxD)
L216.2XW128.5XH34mm
Net Weight
0.47kg
Power consumption
14W(Max)
