6. Assembly procedure
7
2
Installing the storage basket
Align the hooks on the
bottom of the storage
basket with the frame of
the front drive base, then
push the storage basket
straight down. Push the
flat part at the bottom of
the basket until it clicks.
1
Assembling the front drive base and rear drive base
Grab the handle near the
center of the front drive
base while tilting up the
rear drive base. Then
align Bar B with the hook
on the rear drive base.
Slowly tilt the rear drive
base forward and connect
it to the front drive base.
The base release handle
of the rear drive base
latches onto Bar A of the
front drive base. A click
will be heard when the
two parts are connected
properly.
Click
Handle
Bar A
Bar B
If the device does not start properly even though a charged battery is inserted
to the device and the device is turned on, remove the battery, then re-insert the
battery after 10 seconds.
To Next Page
