GB31
REPLACING THE OVEN LAMP
To replace the rear lamp (if present):
1. Disconnect the oven from the power supply.
2. Unscrew the lamp cover (Fig. 6), replace the lamp (see note for lamp type) and screw the lamp cover
back on.
3. Reconnect the oven to the power supply.
To replace the side lamp (if present):
1. Disconnect the oven from the power supply.
2. Remove the side accessory holder grilles, if present (Fig. 3).
3. Use a screwdriver to prise off the lamp cover (Fig. 7).
4. Replace the lamp (see note for lamp type) (Fig. 8).
5. Reposition the lamp cover, pushing it on firmly until it snaps into place (Fig. 9).
6. Refit the side accessory holder grilles.
7. Reconnect the oven to the power supply.
N.B:
- Only use 25-40W/230V type E-14, T300°C incandescent lamps, or 20-40W/230 V type G9, T300°C halogen
lamps.
- Lamps are available from our After-sales Service.
IMPORTANT:
- If using halogen lamps, do not handle with bare hands since fingerprints can damage them.
- Do not use the oven until the lamp cover has been repositioned.
Fig. 6 Fig. 7 Fig. 8 Fig. 9

Whirlpool AKZM 756 Specifications

General

Oven type	Electric
Self-cleaning	Yes
Oven thermostat range	0 - 250 °C
Auto programs quantity	10
Total oven(s) interior capacity	67 L
Timer type	Digital
AC input voltage	230 V
AC input frequency	50 Hz
Energy consumption	0.99 kWh
Installation compartment dimensions (WxDxH)	560 x 550 x 600 mm
Product color	Stainless steel
Package weight	42500 g

Weight and Dimensions

Depth	564 mm
Width	595 mm
Weight	40500 g
