Whirlpool AMC 993 - Page 7

35
The actual unit may be different than the picture shown
Indoor Unit
Outdoor Unit
1.
Key switch
2.
Front panel
3.
Filter
4.
Guide louver
5.
Receiving windows
6.
LED Board
7.
Wall pipe
8.
Wrapping Tape
9.
Indoor & outdoor
cable
10.
Drainage Pipe
Air outlet
Air inlet
Remote
Control
Air outlet
Air inlet
AMC 994
Signal receiver Dehumidify On Temperature Cool Heat
