SERVICE
23.07.1999 / Page 4 AWM243 Whirlpool Europe
Doc. No: 4812 712 14543 8570 243 42001 Customer Service
Spare part list
Model AWM 243
Service No. 857024342001
Version 857024342001
Pos. No. 12NC Code Description
001 0 4819 440 19716 Cabinet
003 0 4812 464 48099 Traverse
011 0 4819 462 48472 Foot
021 0 4819 440 19715 Front
021 1 4812 440 19343 Flap
024 0 4819 440 19892 Panel, rear
024 1 4819 418 79837 Box hose
025 0 4812 440 19346 Holder Control Device
030 0 4812 440 19531 Cover plate
040 0 4812 417 18787 Hinge
053 0 4819 440 19791 Plinth
061 0 4812 466 88458 Counter weight upper
061 1 4812 466 88459 Counter weight front
080 0 4812 529 18038 Shock absorber 800-1000
084 0 4812 466 58001 Silent bloc
086 2 4812 401 18412 Stopper
110 0 4812 498 18139 Handle,door white
130 0 4812 417 28046 Lock Door
130 1 4812 417 28045 Pin Door Lock
131 0 4812 417 28047 Plate Door lock
131 1 4812 417 28048 Plate Doorlock Lower
141 0 4812 450 68219 Door glass
143 0 4812 440 19342 Glassdoor frame
144 0 4812 459 28043 Frame,door glas
144 1 4812 498 18137 Knob Door safety
144 2 4812 492 58023 Spring Door Safety
144 3 4812 290 68153 Holder,adjust. Door Safety
190 0 4812 460 68527 Door bellow
190 1 4812 492 18017 Strap
190 2 4819 530 58059 Ring
200 1 4819 418 18378 Tub front
200 2 4819 418 18381 Tub non removable 400/500
200 4 4812 290 88054 Clamp for tub WH
220 0 4819 418 18329 Drum
223 0 4819 515 28267 Agitator
271 0 4812 358 18056 V-ribbed belt WH 1250 J5
272 0 4819 528 88112 Pulley
292 0 4812 530 58101 Gasket Tub
301 0 4819 453 19794 Control panel
303 0 4819 498 78177 Handle
331 0 4819 412 58532 Knob,timer
331 1 4812 413 18198 Adapter Button
332 0 4812 410 28562 Push button
335 0 4819 412 58534 Knob Thermostat
354 1 4819 134 48501 Pilot lamp
401 0 4819 361 58182 Motor
420 0 4819 121 18267 Capacitor
421 0 4819 121 18271 Interf.filter
430 0 4812 360 18383 Pump
451 0 4819 259 28932 Heating element
490 0 4819 321 18234 Cable,mains
490 1 4812 321 28367 Strain relief
504 0 4819 282 18743 Timer
554 0 4819 282 48313 Thermostat
571 0 4812 271 28375 Valve,magnet Single
Pos. No. 12NC Code Description
581 0 4812 271 28381 Pressostat EATON
620 1 4819 410 29005 Switch Options N.C.
621 0 4819 410 29004 Switch ON/OFF
630 0 4812 280 58019 Door lock
701 0 4819 530 28848 Hose, inlet
701 1 4819 466 69704 Gasket and filter
702 0 4819 530 29019 Hose intern
707 0 4812 526 48031 Nozzle Distribution
707 1 4812 526 48028 Nozzle
708 1 4812 530 48143 Bend
711 0 4812 418 88026 Dispenser WH-4CH
712 0 4812 418 78047 Drawer
713 0 4812 418 88028 Flap Detergent Cont.
717 0 4819 321 28092 Bowden cable
717 1 4812 321 38013 Lever , Nozzle
717 2 4812 321 38012 Holder,adjust.
717 3 4812 278 88007 Slide
717 5 4819 528 38444 Cam
718 0 4812 526 48032 Siphon
718 1 4812 418 88024 Accessory
750 0 4819 526 48474 Container
753 1 4819 418 68234 Chamber,air
754 0 4812 530 28826 Drainhose
754 1 4812 530 28832 Lock eco
754 2 4812 530 28829 Flange eco
760 0 4812 480 58075 Filter Set Pump
760 1 4812 418 68138 Gasket Sieve / Rough
781 0 4819 530 29032 Hose,draining
781 1 4819 530 28977 Pipe,exhaust
783 0 4812 530 28827 Hose Pressostat
787 0 4812 530 28813 Hose
794 5 4812 530 58095 Gasket Air trap
901 0 4819 401 18868 Clamp,hose
901 2 4819 401 18872 Clamp,hose
901 3 4812 401 18414 Clamp,hose
902 0 4812 290 88049 Bracket
902 1 4812 255 18204 Holder Hose outlet
903 0 4812 255 18205 Holder Pressostat
903 5 4812 290 88048 Cable clamp
903 7 4819 401 18823 Clamp
903 9 4812 290 88046 Cable clamp
910 1 4812 505 18368 Nut M10
911 7 4812 903 08014 Screw M5x12
923 0 4812 532 18024 Washer
931 0 4819 492 38139 Spring Suspension
932 3 4812 492 58022 Spring Door Lock
932 5 4812 492 38359 Spring , Nozzle
941 0 4812 520 28002 Bearing,ball 6203 2Z C3
941 1 4819 520 18034 Bearing 6202 2Z
952 0 4819 466 69882 Gasket thermostat
953 0 4819 532 78223 Ring
961 0 4812 321 48004 Cover
990 0 4819 310 39227 Mounting kit Weight top
990 1 4819 310 39228 Mounting kit Weight bottom
993 0 4812 530 48017 Bow
