12
CODE EXPLANATION
A1. 00 PREWASH LENGTH
A1. 00
!
This is the number of minutes of PREWASH.
Choose 0 to disable the prewash or select between
2 and 7 minutes by pressing the
HOT
button.
Press the
WARM
button once to advance
to next code.
If cycle counter (9 0C) is selected, the following is true:
This is “VIEW ONLY” and cannot be cleared.
Press the
WARM
button once to advance to next code.
If money counter (1.0C or 1.C0) is selected, the following
is true:
END OF SET-UP PROCEDURES
EXIT FROM SET-UP MODE
!"Close the service access door.
!""Disconnect washer from power before reinstalling the AA1
connector, if it was removed.
!"Remove the manual set-up card.
3 00 Number of dollars
in HUNDREDS
3 01 = $100.00
4 00 Number of dollars in ONES
4 68 = $ 68.00
5 00 Number of CENTS
5 75 = $ .75
TOTAL = $168.75
1 00 Represents the number
of cycles in HUNDREDS
1 02 = 200
2 00 Represents the number
of cycles in ONES
2 25 = 25
TOTAL CYCLES = 225
