CONSUMER SERVICES TECHNICAL

EDUCATION GROUP PRESENTS

Service Manual

Part No.

Whirlpool Commercial

HE Front Loading Washers

Models CHW9050 & CHW9060

CL-18

Service Manual

Part No. W10602873

Table of Contents

Other manuals for Whirlpool CHW9060

Installation Instructions28 pages

Questions and Answers:

C
colemanmorganAug 16, 2025
Why won't my Whirlpool CHW9060 Washer power up?
- B
  Brian SextonAug 16, 2025
  If your Whirlpool washer isn't powering on, there are several things you can check: * Ensure the washer is properly plugged into a working outlet and that no fuses have blown. * Check the continuity of the line cord and RFI line filter, replacing them if necessary. * Inspect the wire harness connecting the CCU with the UI, and replace if needed. * Use a multimeter to check for power going from the RFI line filter to the Central Control Unit (CCU) and transformer, and from the transformer to the User Interface (UI). * Listen for a click in the CCU when the washer is plugged in. If there's no click, replace the CCU; if there is a click, replace the UI.
E
evansnathanAug 19, 2025
What to do if my Whirlpool CHW9060 Washer won't drain?
- E
  erica38Sep 12, 2025
  If your Whirlpool washer isn't draining, here are some troubleshooting steps: * Unplug the washer or disconnect power first. * Inspect the wire harness connections. * Check the drain pump and drain pump motor for any issues. * Ensure the drain hose and drain pump filter are free of obstructions, and the hose isn't crushed, kinked, or inserted too far into the stand-pipe. * Verify the drain isn't trying to pump water higher than 96 inches from the washer's base.
A
Austin RayAug 22, 2025
How to fix a Whirlpool CHW9060 that won't start cycle?
- J
  Joy WellsAug 22, 2025
  If your Whirlpool washer isn't starting a cycle, try these steps: * Open and close the door, ensuring it's opened between consecutive wash cycles. * Check the door lock/latch assembly using the diagnostics. * If the door is locked, drain the washer either in a diagnostic mode or by draining from the pump manually. * Check the wire harness connections of the door lock and the UI–CCU.
B
Brianna TurnerAug 26, 2025
Why is my Whirlpool CHW9060 vibrating so much?
- E
  Emily HarrisonAug 26, 2025
  If your Whirlpool washer is vibrating excessively, consider the following: * Ensure the shipping system has been completely removed. * Double-check the installation to confirm it meets requirements. * Inspect the leveling feet, making sure all legs are locked to the base and firmly contacting the floor.
D
Daniel HarrisAug 28, 2025
What to do if my Whirlpool Washer touch pads do not respond?
- R
  rayjeromeAug 28, 2025
  If the touch pads on your Whirlpool washer aren't responding, try these troubleshooting steps: * Verify the use of buttons in set-up mode. If the buttons respond, go to 'WON’T START CYCLE'. * Check the connection of the matrix key board with the user interface, ensuring the ribbon connector isn't folded over backwards. * Inspect for corrosion in and at the base of the ribbon connector socket on the UIC; replace the UIC if corrosion is present. * Replace the keypad assembly.
D
Darrell SnowAug 31, 2025
Why won't my Whirlpool CHW9060 Washer fill with water?
- K
  Kevin RomanAug 31, 2025
  If your Whirlpool washer isn't filling with water, try these steps: * Verify that both hot and cold water faucets are fully open and that adequate water pressure is available. * Check the inlet valves for any issues. * Inspect the water connections to the washer, ensuring the supply hoses are unobstructed, not reversed, and the screens aren't plugged. * Check the operating pressure switch and air hose for any obstructions. * Confirm the drain pump motor isn't running during the fill cycle and that water isn't siphoning out of the drain hose.
A
andrewcalderonSep 3, 2025
Why is my Whirlpool CHW9060 motor overheating?
- N
  Nancy PerrySep 3, 2025
  If the motor in your Whirlpool washer is overheating, consider these potential causes: * Check the drive motor itself. * Confirm the correct voltage is being supplied to the washer. * Inspect the wire harness connections and the drive belt. * Look for any clothing obstructions between the spinner and the outer tub.
N
Norma ChavezSep 6, 2025
Why is my Whirlpool CHW9060 Washer overfilling with water?
- N
  Nathan Rasmussen PhDSep 6, 2025
  If your Whirlpool washer is overfilling, here are a few things to investigate: * Make sure the washer is properly leveled. * Check the pump drain system for any signs of drainage failure. * Inspect the operating pressure switch and the pressure switch hose.
H
Henry SmithSep 9, 2025
Why won't my Whirlpool Washer dispense detergent?
- A
  Amanda FordSep 9, 2025
  If your Whirlpool washer isn't dispensing detergent, consider the following: * Ensure the washer is level. * Check that the dispenser drawer isn't clogged with detergent and that the fill tube from the dispenser to the outer tub isn't blocked by clothing. * Inspect the water connections to the washer, checking for plugged screens in the water source. * Verify the pressure switch is operating correctly and that there is no water in the washer. * Look for indications of over-sudsing and check Help codes.
S
Stacey WalkerSep 12, 2025
Why won't the spin basket rotate in my Whirlpool CHW9060 Washer?
- I
  ismithSep 12, 2025
  If the spin basket in your Whirlpool washer isn't rotating, check these components: * Inspect the drive belt. * Check the drive motor. * Inspect wire harness connections and perform a continuity test on the cables between the MCU and motor, and between the MCU and CCU. * Check the MCU by looking for operations of the drive motor.

Whirlpool CHW9060 Specifications

General

Brand	Whirlpool
Model	CHW9060
Category	Washer
Language	English

Summary

GENERAL INFORMATION AND SAFETY

WASHER SAFETY

Crucial safety precautions for operating the washing machine.

MODEL AND SERIAL NUMBER INFORMATION

MODEL & SERIAL NUMBER DESIGNATORS

Explains the meaning of characters in model and serial numbers.

MODEL & SERIAL NUMBER LABEL LOCATION

Shows the location of the model and serial number label and tech sheet.

SPECIFICATIONS AND WARRANTY

SPECIFICATIONS

Details the technical specifications of the Whirlpool HE Front Loading Washers.

WARRANTY

Outlines the warranty terms and conditions for the product.

INSTALLATION REQUIREMENTS

TOOLS AND PARTS

Lists required tools and parts for proper installation.

LOCATION REQUIREMENTS

Specifies the necessary environmental and space requirements for installation.

DRAIN SYSTEM

Details the requirements and methods for connecting the drain system.

ELECTRICAL REQUIREMENTS

Outlines the electrical supply and connection requirements for the washer.

SHIPPING BOLTS

Instructions on removing and reinstalling shipping bolts for transport.

BASIC OPERATION

SET UP INSTRUCTIONS

Step-by-step guide for initial setup and operation of the washer.

GENERAL USER INFORMATION

Provides general information for users operating the washer.

PAYMENT SYSTEM CONVERSION

Instructions for converting from coin slide to coin drop payment systems.

CONTROL SET-UP PROCEDURES

Procedures for setting up and programming the washer controls.

COMPONENT ACCESS AND SERVICE

COMPONENT LOCATIONS

Diagram showing the location of various internal components for service.

CHEMICAL DISPENSER

Details the chemical dispenser drawer and its parts for servicing.

CONTROL PANEL AND FACIA

Instructions for accessing and removing the control panel and associated parts.

CENTRAL CONTROL UNIT (CCU)

Instructions for accessing and removing the Central Control Unit (CCU).

WATER INLET VALVES

Procedure for accessing and removing the water inlet valves.

DOOR LOCK / LATCH ASSEMBLY

Steps to access and remove the door lock/latch assembly for service.

DRAIN PUMP

Instructions for accessing and removing the drain pump assembly.

DRIVE MOTOR

Steps to access and remove the drive motor for service.

OUTER TUB AND SPIN BASKET ASSEMBLY

Detailed steps for removing the outer tub and spin basket assembly.

COMPONENT TESTING AND DIAGNOSTICS

INLET VALVE SOLENOIDS TESTING

Procedures to test inlet valve solenoids for proper resistance.

PRESSURE SWITCH TESTING

Procedures to test the pressure switch for continuity and function.

DOOR LOCK ASSEMBLY TESTING

Tests for the door lock assembly, including switch and wax motor.

DRIVE MOTOR TESTING

Procedures to test the drive motor resistance and continuity.

DIAGNOSTIC MODES OVERVIEW

Overview of washer diagnostic modes, including error codes.

TROUBLESHOOTING GUIDE

A guide to troubleshooting common washer problems and their causes.

WIRING DIAGRAM AND GROUNDING

WIRING DIAGRAM

Schematic showing electrical connections and component layout.

GROUNDING SYSTEM

Information on the grounding system and its importance for safety.
