INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before
starting installation. Read and follow the
instructions provided with any tools listed
here.
Tools needed to connect the water inlet hoses:
• Pliers (that open to 1 9/16th” {39.5 mm})
• Flashlight (optional)
Tools needed for installation:
• 1/2” socket and wrench
• 9/16” open end wrench
• Level
• Wood block
• Ruler or measuring tape
The installation may require additional parts.
A. U-shaped hose form
B. Water inlet hoses (2)
C. Inlet hose washers (4)
D. Transit bolt hole plug (4)
E. Beaded tie strap
F. Drain hose
G. Hose clamp
Parts supplied:
For complete installation instructions,
see the Document links page.
A B
D E
C
F
G
