6-8
QUICK OVERVIEW TEST
n This cycle consists of 8 steps. In each step, the washer will perform a Control Action as
described in the table below. Once the action is completed, the cycle will advance to the next
step.
n Each step can be differentiated from the others by looking at the display indication. Each step
has a different message displayed.
n To advance to the next step before the control action is completed, press any button except
COLD.
n To exit from the Quick Overview Test, press the COLD button.
Step Display Indication Control Action Actuators to be checked
1 Delicates Door locks, basket turns 1/2 revolution,
then door unlocks and relocks.
n Door lock system
n Child safety routine
n Motor control (MCU)
2 CCU EEPROM Version
& Knits
Fill by both cold water inlet valves
(4 liters) into BLEACH compartment
n Cold water inlet valves #1
and #2
n Pressure switch: Suds Level
3 CCU Software Version
Woolens
Fill by hot water inlet valve to Wash
Level into MAIN WASH compartment.
n Hot water inlet valve
n Pressure Switch:
Wash Level
4 MCU Software Version
Whites
Basket executes tumbling at wash
speed (30 seconds).
n Motor
n Motor control (MCU)
5 MCU Hardware Version
Brights
Basket executes tumbling at wash
speed (30 seconds).
n Motor
n Motor control (MCU)
6 UIC EEPROM Version
Colors
Drain pump is ON. n Drain pump
n Pressure switch*
7 UIC Software Version
Permanent Press
Basket rotates counter-clockwise
and ramps up. Performs unbalance
procedure before and after spinning.
If not interrupted, the basket will slow
and stop; after reaching 0 rpm, the door
unlocks and Step 8 will be skipped.
n Motor
n Motor control (MCU)
n Drain pump on
8 Delicates This step is only apparent if Step 7 is
MANUALLY ADVANCED prior to the
basket reaching 0 rpm (washer pumps
out if needed). Door unlocks (washer
returns to ashing mode).
n Drain pump
(if water is present)
n Door unlock
The drain pump may be running in any of the last 3 steps, depending on the water level in the washer and
position of the pressure switch.
*The washer will drain until pressure switch reaches lowest level for 10 seconds, then moves to next step.
