4-26
4. Use a flat blade screwdriver to press the two
locking tabs in the bottom slots to release
the switch.
5. Slide the switch up and pull it out of the slots
to remove it.
6. Remove the two wires from the clips on
each side of the ground switch and pull the
connectors off the spade terminals.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the lower service panel
(See page 4-21)
or
Remove the back panel (See page 4-28).
GROUND SWITCH
Locking Tabs
Wire Connectors
Wire Clips
Back Ground Switch
Front Ground Switch
To Next Page
