Whirlpool GBS277PDB - Strip Circuits; Maxi Broil

7-3
STRIP CIRCUITS
BAKE & PREHEAT-BAKE
ECONO BROIL
MAXI BROIL
BAKE-2000W
OUT BROIL-1000W
R
BU
R
L1
L2
IN BROIL-1667W
OR
OR
GY
N
~
M
BLOWER
P5-3
P5-1
P5-2
P1-5
R
W
BU
BK
BK
P4-1
P4-2
BK
P1-1
~
M
IN BROIL-1667W
OR
L1
L2
GY
N
BLOWER
P5-2
P1-5
R
W
OR
BK
BK
P4-1
P4-2
BK
P1-1
~
M
OUT BROIL-1000W
BU
L1
L2
IN BROIL-1667W
OR
GY
N
BLOWER
P5-1
P5-2
P1-5
R
W
BU
OR
BK
BK
P4-1
P4-2
BK
P1-1
