4-3
6. Use a 16 mm open-end or an adjustable
wrench and remove the hex nut from the
sealed burner you are replacing. Lift the
sealed burner off the gas line.
8. Remove the screw from the ignitor bracket
and remove the ignitor from the sealed
burner.
7. Disconnect the wire from the ignitor con-
nector.
REASSEMBLY NOTE: When you reinstall the
sealed burner, make sure that you keep the
burner straight so that the ignitor is aligned in
the cooktop hole when it is lowered. Also, do
not cross-thread the hex nut or overtighten it.
Ignitor
Screw
16 mm
Hex Nut
Sealed
Burner
Gas
Line
Ignitor
Wire
To Next Page
