Valve Parts List
To order repair parts call toll free 1-866-986-3223.
Manufactured and warranted by
Water Channel Partners
1890 Woodlane Drive
Woodbury, MN 55125
Questions? Call Toll Free 1-866-986-3223 or visit whirlpoolwatersolutions.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal, typically located on the rim below the salt lid hinges.
Key
No.
Part No. Description
– 7384683
Motor, Cam & Gear Kit, 3/4"
(includes Key Nos. 50-52)
50
á
Motor
51
á
Cam & Gear
52 7338111 Screw, #6-19 x 1-3/8" (2 req.)
53 7337474 Motor Mount
54 7030713 Switch
– 7331185
Drain Hose Adaptor Kit
(includes Key Nos. 55-59)
55
á
Clip, Drain
56
á
Drain Hose Adaptor
57
á
Hose Clamp
58
á
O-Ring, 5/8" x 13/16"
59
á
Flow Plug, 2.0 gpm
– 7129716 Seal Kit (includes Key Nos. 60-65)
60
á
O-Ring, 7/16" x 5/8"
61
á
O-Ring, 3/4" x 15/16"
62
á
O-Ring, 3-3/8" x 3-5/8"
63
á
Rotor Seal
64
á
O-Ring, 3/8" x 9/16"
65
á
Seal, Nozzle & Venturi
66 7082087 Wave Washer
67 7199232 Rotor & Disc
– 7342665
Drain Plug Kit, 3/4"
(includes Key Nos. 64, 68 & 69)
68
á
Plug, Drain Seal
69
á
Spring
70 7337563 Clip, 3/4", pack of 4
71 7370286
Bypass Valve Assembly, 3/4", in -
cluding 2 O-Rings (See Key No. 72)
Key
No.
Part No. Description
72 7337571 O-Ring, 15/16" x 1-3/16", pack of 4
– 7113040
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 73 & 74
73
á
Turbine Support & Shaft
74
á
Turbine
75 7082053 Valve Body
76 7081201 Retainer, Nozzle & Venturi
77 7342649 O-Ring, 1/4" x 3/8", pack of 2
78 1202600 Nut - Ferrule
79 7120526 Elbow, 90°
80 7292323 O-Ring, 3/16” x 7/16”
81 7238450
Nozzle & Venturi Assembly
(incl. Key Nos. 76, 77 & 82-91)
82
á
Housing, Nozzle & Venturi
83
á
Cone Screen
84
á
Flow Plug, 0.3 gpm
85
á
Gasket
86
á
Nozzle & Venturi Disc, Red
87
á
Flow Plug, 0.1 gpm
88
á
Screen
89
á
Screen Support
90
á
O-Ring, 1-1/8" x 1-3/8"
91
á
Cap
¢
7290957
Repl. Nozzle, Venturi & Gasket Kit
(includes Key Nos. 77, 83, 85, 86
& 90)
92 7309803 Wire Harness, Sensor
93 7337466 Valve Cover
94 7342657 Screw, #10-14 x 2", pack of 5
¢ Not illustrated
