Kitchen Aid Modular Steam
Function
Kitchen Aid Modular Steam
Artisan Tray Management
The Artisan tray tool is controlled from the control board that can communicate with UI and
update all system information. For this type of ovens, is foreseen an electromechanical
switch that detect the presence or not of the tray, this presence is read from Control board
from pin 1 and 3 (connector P8) that has to send a message to Navigator to inform its about
the insertion of the tray.
The accessory working just if the tray is inserted.
Mechanical switch will be read like a button with this logic:
0V no accessory inserted 5V accessory connected
