Components
Cooling Fan Induction Power Control IPC
Induction Oven
Single components of cooling fan
Coil with electronic circuit on the rear side of the printed circuit board
Permanent magnet
1 3 2
1
Single components from top down to left, bearing, spring, fanwheel and coil with
driver electronic
2
3
View to the printed circuit board and driver electronic
