Functional characteristics
Thermostat 285°C
Induction Oven
Specification of thermostat left upper position:
Pos. No. 5570 / 12NC 4810 105 39905
•Rating Voltage 250V
•Rating Current 16A
•Maximum ambient operating temperature 300°C
•Normally closed contact 285°C +/- 15°C
•Manual resettable (pull reset pin)
•Marking colour green
