Whirlpool Pro Series - Page 27

27
Valve Parts List
Questions? Call Toll Free 1-866-986-3223 or visit whirlpoolwatersolutions.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal, typically located on the rim below the salt lid hinges.
Key
No.
Part No. Description
– 7384691
Motor, Cam & Gear Kit, 1"
(includes Key Nos. 100-102)
100
á
Motor
101
á
Cam & Gear
102 7224087 Screw, #8-32 x 1" (2 req.)
103 7231393 Motor Plate
104 0900857 Screw, #6-20 x 3/8" (3 req.)
105 7171250 Bearing
– 7331169
Drain Hose Adaptor Kit
(includes Key Nos. 106-110)
106
á
Clip, Drain
107
á
Hose Clamp
108
á
Drain Hose Adaptor
109
á
O-Ring, 15/16" x 1-3/16"
110
á
Flow Plug, 2.0 gpm
– 7185487 Seal Kit (includes Key Nos. 111-116)
111
á
O-Ring, 5/8" x 13/16"
112
á
O-Ring, 1-1/8" x 1-1/2"
113
á
O-Ring, 4-1/2" x 4-7/8"
114
á
Rotor Seal
115
á
Seal
116
á
Seal, Nozzle & Venturi
117 7174313 Bearing, Wave Washer
118 7185500 Rotor & Disc
Key
No.
Part No. Description
– 7342712
Drain Plug Kit, 1"
(includes Key Nos. 115, 119 & 120)
119
á
Plug, Drain Seal
120
á
Spring
121 7337589 Clip, 1", pack of 4
122 7342704
Installation Adaptor, 1", pack of 2,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
123 7337597 O-Ring, 1-1/16" x 1-5/16", pack of 4
124 7214383
Bypass Valve Assembly, 1",
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
– 7290931
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
123) & 1 ea. of Key Nos. 125 & 126
125
á
Turbine Support & Shaft
126
á
Turbine
127 7171145 Valve Body
128 7309811 Wire Harness, Sensor
– 7398705
Nozzle & Venturi Kit
(includes Key Nos. 129-131)
129
á
Retainer, Nozzle & Venturi
130
á
O-Ring, 1/4" x 3/8" (2 pcs.)
131
á
Nozzle & Venturi Assembly
132 7175199 Wave Washer
133 7171161 Valve Cover
134 7342681 Screw, #10-14 x 2-5/8", pack of 8
135 7305150 Switch
136 7140738 Screw, #4-24 x 3/4" (2 req.)
To order repair parts call toll free 1-866-986-3223.
Manufactured and warranted by
Water Channel Partners
1890 Woodlane Drive
Woodbury, MN 55125
