User manual
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In o
rder to receive a more complete assistance,
please register your product on
www.whirlpool.com.hk/www.whirlpool.com.sg
CONTROL PANEL
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bracket is removed.
For more detailed instructions on how to remove it, see the Installation Guide.
1 Programme selector
2 “Start/Pause“ button
3 “Reset“ button
4 “Temperature“ button
5 “Start delay“ button
6 Child lock combination
7 “Spin“ button
8 Time
9 Temperature
10 Washing phase
INDICATORS
Detergent over dosage
Door open
Failure: Service
Failure: Clean pump
Failure: Water tap closed
In the event of any failure, refer to the
“TROUBLESHOOTING“ section
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Lid handle
2. Lid
3. Control panel
4. Detergent dispenser
5. Drum
6.
Water filter -
behind the cover
7. Mobility lever (depending on model)
8. Adjustable feet (x2)
5.
1.
6.
7.
2.
3.
4.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover or
water softener.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch. Bleach.
Pour in softener, starch or bleach solution only
up to the “max” mark.
Release button

Press to remove tray for cleaning.

1 2 3 4 5 6
7
10 89
Max load 7,0 Kg
Detergents and additives
Recommended
detergent
Colors 15°
Fresh Care
Programme
Temperatures
Max.
Spin
speed
(rpm)
Max
load
(kg)
Duration
(h : m)
Prewash
Main
wash
Softener
Powder Liquid
Setting Range
Rapid 30’ 30°C 20 - 30°C 1000 3,0 0:30 –
 
–

Eco Cotton 60°C 40 - 60°C 1000 7,0 4:00 –
   
Drum clean
95°C 95°C
0 0,0
1:20
–
   
Antistain 20°C 20°C 1000 4,0
2:30
–
   
Hygiene 60°C 60°C 1000 7,0
2:30
   
Sport 30°C 20 - 30°C 1000 3,0
1:55
   
–
Business 40°C 20 - 40°C 800 1,5
0:45
  
–

Rinse & Spin – – 1000 7,0 ** – –

– –
Spin – – 1000 7,0 ** – – – – –
Wool 40°C 20 - 40°C 1000 1,0
0:35
–
 
–

Delicates 40°C 20 - 40°C 1000 1,5
0:45
  
–

Synthetics 40°C 20 - 60°C 1000 3,0 1:40
    
Cotton 60°C 20 - 95°C 1000 7,0 2:35
    
Mixed 45‘ 40°C 40°C 1000 7,0
0:45
–
   

Dosing required  Dosing optional
** The duration of the programme is shown on the display.
6th Sense - The sensor technology adapts water, energy and programme duration to your
wash load.
Eco Cotton 60°C- Reference wash cycle.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options.
– –
–
–
–
–
– –
– –
–
– –
Options
Rapid
Prewash
Intensive
Rinse















–
–
–
–


–
–





–







–
–
–





–
–
–
–
–

–
–
–
–
–
–


