Whirlpool WHELJ1 - Valve Assembly Parts List

27
Valve Parts List
Key No. Part No. Description
50 7224087 Screw, #8-32 x 1” (2 req.)
51 7286039 Motor (incl. 2 ea. of Key No. 50)
52 0900857 Screw, #6-20 x 3/8” (2 req.)
53 7231385 Motor Plate
54 0503288 Bearing
55 7284964 Cam & Gear
56 7142942 Clip, Drain
57 0900431 Tubing Clamp (2 provided)
58 7024160 Adapter, Drain Hose
59 7170327 O-Ring, 5/8” x 13/16”
60 7290410 Flow Plug
61 7170238 O-Ring, 7/16” x 5/8”
62 7170212 O-Ring, 3/4” x 15/16”
63 7082087 Wave Washer
64 7199232 Rotor & Disc
65 7170246 O-Ring, 3-3/8” x 3-5/8”
66 7134224 Rotor Seal
67 7170204 O-Ring, 3/8” x 9/16”
68 7092642 Plug, Drain Seal
69 7129889 Spring
70 7116713 Clip (2 req.)
71 7278442 Installation Adapter (2 req.)
72 7170288 O-Ring (2 req.)
73 7082053 Valve Body
74 7081764 Seal, Nozzle & Venturi
75 7170319 O-Ring, 1/4” x 3/8” (2 req.)
76 7100940 Plug, Aspirator Port
77 7081201 Retainer, Nozzle & Venturi
78 7085263 Valve Cover
79 7074123 Screw, #10-14 x 2 (5 req.)
80 7077472 Expansion Pin
81 7030713 Switch
82 7117816 Spacer
83 7070412 Screw, #4-24 x 1-1/8”, Flat Head
