Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
CHART NO. - 1
YES
YES
YES
YES
YES
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 32 of 44
WATER NOT FILLING
Is M/c switch on?
Water at the tap end?
Switch on the M/c
Ensure water at the tap
end
Kinked / Clogged
inlet hose
Remove / Clean inlet
hose
Is clogged inlet valve
filter?
Clean inlet valve filter
IS INLET VALVE DEFECTIVE
(Check coil resistance using a
multimeter.It shold read 4k to 5k ohms.If
not, indicates defective.Feed 220V AC to
its lugs, if not operating, indicates
defective)
Replace inlet valve
YES
NO
NO
NO
NO
NO
To Next Page
