Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
YES
YES
CHART NO. - 2
YES
YES
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 33 of 44
IS PCB DEFECTIVE?
(Check any loose contact and then on START
mode check 220V AC at the end of two wire of
valve inlet using a multimeter.If not, indicates
PCB defective
Replace PCB
IS WIRING HARNESS DEFECTIVE?
(Check wire continuity using multimeter)
Replace wiring harness
WATER OVER FLOWING
Is pressure hose/ leaky /
kinked / blocked
Arrest / Replace
pressure hose
Leaky valve inlet?
Replace valve inlet
*
NO
NO
NO
NO
YES
To Next Page
