WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 34 of 44
Is Pressure switch
defective?
Replace Pressure switch
Is air dome clogged?
Clean air dome
Is PCB Compatible /
Defective
Replace PCB
CHART NO. - 3
NO DRAIN
Drain hose hook up? Place the drain hose at
the ground level
Drain hose kinked /
Clogged?
Remove / clean drain
hose
*
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
YES
