Page 8 | 1-800-343-9463
WCM 021219
Mounting Bracket (Paintable)
Supply and Return Grille (Paintable)
Evaporator Unit
Electrical Knockouts
Line Set Knockout (x6)
CEILING MOUNT 4000 SPECIFICATIONS
Model
4000 Evaporator
(Fan Coil Unit)
4000 Condenser
(Air-Cooled Condensing Unit)
Cellar Size Approx. 1000 cu. ft. when cellar is fully insulated and sealed with a proper vapor barrier*
BTU/h w/85°F air entering
condenser coil
4000
Dimensions 35.75”L x 14.5”W x 12.75”H 16.08”L x 16.23” W x 12.61” H
Refrigerant R-134a
HP 1.57
Voltage Rating 115V (15-amp dedicated circuit required) 115V (15-amp dedicated circuit required)
Weight (lbs) 80 56
Amps Evaporator: 1 (running amps), compressor: LRA 43, RLA 8
Line Set Liquid line: ¼” liquid line; suction line ½” (less than 50 ft.), ⁄” (more than 50 ft.)
Drain Line ¼” ID clear plastic tubing (not provided)
Installation
Evaporator is installed in the cellar. Condensing unit can be installed up to 100 line feet from evapo-
rator unit.
Thermostat Aftermarket (24V thermostat not included)
Temp. Delta
Can maintain a 55°F cellar temperature with up to 110°F condenser air intake temperature
Warranty Two-year limited warranty (parts and labor)
