2010 Edition 1 Page 16
WHYTE Service Manual
5.2: WHYTE ADJUSTABLE DROPOUT SYSTEM
5.3: GENERAL WHYTE HARDTAIL MTB LUBRICATION
For the correct lubrication regime and maintenance of all parts on a Whyte hardtail bicycle,
please refer to the specific component manufacturers detailed instructions bundled with
this manual or for further information visit the specific manufacturers website.
Point Description Lubricant Lubrication Interval
1 LH & RH Dropout Plate Pivot Area (Face Only) SKF Anti Fret Paste Check Once a Month
2 RH SS Plate Pivot Area (Face Only) SKF Anti Fret Paste Check Once a Month
3 LH & RH Dropout Plate Clamp Area (Face Only) SKF Anti Fret Paste Check Once a Month
4 RH SS Plate Clamp Area (Face Only) SKF Anti Fret Paste Check Once a Month
Fig.6: Whyte Adjustable Dropout lubrication
