WHYTE Service Manual
Frame Size
Small Medium Large
Head Angle 67.5° 67.5° 67.5°
Seat Angle 72.5° 72.5° 72.5°
Top Tube 565.1mm 584.5mm 609.6mm
BB Height* 322.7mm 322.7mm 322.7mm
Stand Over 774mm 800mm 826mm
Wheel Base 1081.6mm 1101.9mm 1128.8mm
Chain Stay 425mm 425mm 425mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
67.5°
72.5°
628.8mm
322.7mm
853mm
1153.8mm
425mm
30.9mm
2.2.6: WHYTE 901 & 905
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø677mm tyres fitted (2.25” / 54-559)
Whyte 905 has an adjustable rear drop-out, see section 3.4. When fully extended rearwards, this adds 10mm to Chain
-stay and Wheelbase lengths. When fully retracted forwards, the reduces Chain-stay and Wheelbase lengths by 10mm.
Frame Size
Small Medium Large
Head Angle 68.0° 68.0° 68.0°
Seat Angle 73.5° 73.5° 73.5°
Top Tube 609.9mm 624.9mm 637.9mm
BB Height* 305mm 305mm 305mm
Stand Over 799mm 814mm 841mm
Wheel Base 1129.4mm 1145.6mm 1159.4mm
Chain Stay 435.0mm 435.0mm 435.0mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
2.2.7: WHYTE 929
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø738mm tyres fitted (2.1” / 52-622).
Whyte 929 has an adjustable rear drop-out, see section 3.4. When fully extended rearwards, this adds 10mm to Chain
-stay and Wheelbase lengths. When fully retracted forwards, the reduces Chain-stay and Wheelbase lengths by 10mm.
