REGULATORY INFORMATION
Wireless functions and operating characteristics
The following tables summarizes the technical details of the wireless tech-
nology:
Technical details Inductive radio Bluetooth LE
Antenna type Integral coil antenna Integral frame antenna
Antenna dimensions Ø 2 mm, L 5 mm 18 mm x 4.5 mm
Modulation FSK GFSK / FHSS
Magnetic field strength -54 dBµA/m @ 10 m -
Output power (EIRP) - 0 dBm / 1 mW
Range 0.3 m 6 m
Center frequency 10.6 MHz 2401 MHz – 2480 MHz
Channel Single Channel 40
Bandwith 660 kHz 2 MHz
Data rate 212 kbps 1 Mbps
Data flow Simplex/Semi duplex Duplex
Protocol Random Access / Pro-
prietary
BLE
81
