Kunststoffschweißtechnik
Spare parts list Chapter 10
Hydraulic Aggregate WIDOS 4400
Pos. Name Piece Order no.
1 Protective mounting 1 101042
2 Pan-head screw M6x16 DIN 912 4 0912F016
3 Cover 1 1010021
4 Control knob for pressure setting 1 101022
5 Bush 1 101047
6 Set screw 1 101050
7 Oil dipstick 1 101021
8 Diaphragm grommet DGM32 2 on request
9 Coupling plug, flat packing 1 VST14
10 Synthetic cap for VMST14 1 VKS14
11 Ring for sealing 16x22.7x1.5 1 D16x22,7
12 Screwed connection 2 101024
13 O-ring 19x1,5 2 D18x1,5
14 Sinter-filter 15x8 41180 2 101045
15 O-ring 19x1,5 2 D11x2
16 O-ring 19x1,5 2 on request
17 Coupling box, flat packing 1 VMU14
18 Synthetic cap for VMU14 1 VKM14
19 Plate "Pressure values" 1 SCHM4600
20 Pan-head screw M4x12 DIN 912 4 0912D012
21 Pressure gauge 1 101008D
22 Valve lever 1 101013
23 Cylinder knob M10 1 101033
24 Bellows 1 101035
25 Plate "Release pressure" 1 SCHD-L
26 Motor 1 A10230
27 Reliev valve 1 101052
28 Reduction M 20x1,5 up to M 16x1,5 1 EV142016
29 Screwed connection M 16x1,5 1 EV1016
30 Pump 1.0 l 1 103103
31 Accumulator 1 101006
32 Ring for sealing 14x18,7x1,5 1 on request
33 Hexagon nut M10 DIN 934 1 0934J
34 Pressure switch 1 ESEK103
35 Pan-head screw M6x45 DIN 912 3 0912F060
36 Pan-head screw M 4x10 DIN 912 1 0912D010
37 Washer M4 DIN 125 1 0125D
38 Circlip M 4 1 on request
39 Angle 1 101020
40 Pan-head screw M4x25 DIN 84 2 0084D025
41 Pressure relief valve DBV 08, 100 bar 1 101053
42 Universal RC - link 1 EE0104
43 Capacitor 12,5 µF 1 EK12220
44 Lever block 1 on request
45 Grub screw M 6x8 DIN 913 2 0913F008
46 Hexagon nut M6 DIN 934 3 0934F
23.06.2015 Working instruction WIDOS 4400 Page 39 / 1 of 44
