Kunststoffschweißtechnik
Spare parts list Chapter 10
Hydraulic Aggregate WIDOS 4400
Pos. Name Piece Order no.
47 Set screw 1 on request
48 Plug-in element P83-1/2"x3/16" 1 101043
49 Pan-head tapping screw 3.5 x 20 4 7971C020
50 Side part 1 1010022
51 Screwed connection PG 13.5 1 EV0113
52 Hexagon nut M 20x1,5 brass 1 on request
53 Connection cable with plug 1 EK32220
54 Socket 2 EST0701
55 Flat-head screw M 4x8 DIN 964 8 0964D008
56 Seal, outside 1 1010023
57 Distributor box 1 EI-DOSE
58 Seal, inside 1 1010024
59 Pan-head screw M4x10 DIN 912 4 0084D010
-- Hydraulic oil HLPD 32 1 l HLPD35
23.06.2015 Working instruction WIDOS 4400 Page 39 / 2 of 44
