Kunststoffschweißtechnik
Starting and operating Chapter 5
22.11.2005 Working Instructions WIDOS 4900 CNC 3.0 (110 V) Page 40 of 76
Display:
2
nd
line:
Diag Clk WICON Param
10:10
next menu by pressing button <Start>
Display:
2
nd
line:
Diag Clk WICON Param
10:10
confirm with button <Enter>
with button <Start> back to basic menu
Display:
2
nd
line:
Diag Clk WICON Param
dtf? 10:10
confirm with button <Enter>, data transfer is started
Attention! Check at the PC if data have been transfered → the PC requires for storing the
data
Display:
2
nd
line:
delete CNC–RAM?
Delete all weldings stored in the RAM
button <+>: the weldings stored in the RAM are deleted (data stored on
PCMCIA card will not be deleted)
button <->: the weldings will not be deleted
press several times button <Start or after a short while appears
automatically:
Display:
2
nd
line:
WIDOS 4900 CNC
22.11.2000 10:10
Basic menu
