Description of the product Chapter 1
22.11.2005 Working Instructions WIDOS 4900 CNC 3.0 (110 V) Page 8 of 76
1.4. Machine overview
No. Denomination
1 Basic machine
2 Control unit
3 Reception box
4 Planer
5 Heating element
1.5. Structure of the CNC 3.0 control unit
No. Denomination
6 Display
7 Operating field
8 Pipe data card or general legitimacy card
9 PCMCIA card
10 Barcode reader
6
9
10
8
8
7
1
2
5
4
3
