widos 4900 CNC 3.0 - Page 44

Kunststoffschweißtechnik
Diagnosis program Chapter 6
22.11.2005 Working Instructions WIDOS 4900 CNC 3.0 (110 V) Page 44 of 76
No. Signification
0014
- The required heating time which was calculated by the programmed welding
parameters is displayed
0015
- The required change over time which was calculated by the programmed
welding parameters is displayed
0016
- The required pressure build-up time which was calculated by the
programmed welding parameters is displayed
0017
- The required cooling time which was calculated by the programmed welding
parameters is displayed
0018
- The required joining pressure which was calculated by the programmed
welding parameters is displayed
0021
- The operation and printout language can be choosen
• 0000 German
• 0001 English
• 0003 French
• 0004 Spanish
0023
- The automatic change to summer or winter time may be switched on or off
• 0000 change summer / winter time switched off
• 0001 change summer / winter time switched on
0025
- Printing weldings from the memory (only serial printer):
• 9999 printing all weldings with the same date
0027
- Connect a laptop (program WICON) and all internal calibration values,
such as printing offset, temperature straight line ramp, etc. are displayed
0029
- Setting the serial printer
• 0000 printout off
• 0001 printout on
0030
- All stored weldings are deleted:
• By entering of 0001 all weldings stored in the RAM memory up to that
time are deleted
• By reapeted entering of 0001 all weldings stored in the PCMCIA – card
memory up to that time are deleted.
0034
- Bit values from 0-1023 appear which will change together with the change
of the corresponding analog values
• 0005 Travel
• 0008 Heating element temperature PT 1000
• 0010 Environmental temperature
• 0011 Pressure (4-20 mA)
0044
- A self-test of the machine and the control unit is performed, as well as a weld
log printout on a connected printer
