Spare parts list Chapter 10
Pos. Name Piece Art.-No.
1 Limit switch, complete 1 ES0102
2 Knife 2 MES170
3 Spacer 2 MU170
4 Flat head screw M 3x8 DIN 965 12 0965C008
5 Disc planer, right 1 214402
6 Ball bearing 2 L6003Z
7 Bolt 1 210410
8 Hexagon nut M 16x1,5 DIN 934 1 0934Y
9 Disc M 16 DIN 125 5 0125P
10 Switch cover for planer 1 091420
11 Flat head screw M 5x10 DIN 7991 2 7991E010
12 Fastener for planer 1 216401
13 Bow grip 1 BG56520
14 Cylinder head screw M 6x16 DIN 912 2 0912F016
15 Cover tube 1 091424
16 Underground line 1x1,5 mm² 1 EL3015GG
17 Grub screw M 5x6 DIN 916 1 0916F006
18 Cylinder head screw M 8x30 DIN 912 2 0912H030
19 Ball button C32 M 8 DIN 319 1 0319-C32
20 Locking bolt 1 091422
21 Grooved taper pin 4x16 DIN 1471 1 1471D016
22 Pressure spring 1 FE006
23 Bush 1 216421
24 Lock nut 1 091423
25 Cylinder head screw M 8x30 DIN 912 2 0912H030
26 End sleeve for strands with ring M 4 1 EA05425
27 Tooth lock washer M 4 DIN 6797 1 6797D
28 Cylinder head screw M 4x6 DIN 84 1 0084D006
29 Connecting cable with plug 1 on request
30 Driving motor 1050 W, 110V 1 AMBF16 110V
31 Motor switch 1 ESMBF16
32 Collector carbon 1 set EKMBF16
33 Disc planer, left 1 214403
34 Chain wheel, small (11 teeth) 1 K38011
35 Chain 3/8" (117 links) 1 K38117
36 Chain joint 1 KSCH38
37 Ball bearing 1 L6020
38 Flat head screw M 8x20 DIN 7991 4 7991H020
39 Chain wheel, large (95 teeth) 1 K38095
40 Cover 1 214404
41 Cylinder head screw M 4x16 DIN 912 2 0912D016
