Kunststoffschweißtechnik
Spare parts list Chapter 10
Pos. Name Piece Art.-No.
1 Shim PTFE 2 211508
2 Control lamp, green 1 H2105
3 Ring nut M 12 DIN 582 1 0582L
4 Lock washer M 12 DIN 127 1 0127L
5 Hexagon head screw M 12x35 DIN 933 1 0933L035
6 Cylinder head screw M 5x25 DIN 912 2 0912E025
7 Disc M 5 DIN 125 2 0125E
8 Lock washer M 5 DIN 127 2 0127E
9 Frame for control 1 211506
10 Oval-head screw M 3x5 DIN 7985 7 7985C005
11 Joining disc PTFE 1 211505
12 Flat head screw M 6x12 DIN 7991 4 7991F012
13 Heating element H 4900, 110 V 1 H4900C1 110
Heating plate new 1 HP4900C1 110
Heating plate for change 1 HPT4900C1 110
14 Temperature probe PT1000 1 H09082
15 Handle 2 H0205
16 Handlebar 2 H0206
17 Cable socket 16/15 f. Pg.16 1 EVK1615
18 Rubber cable 5x1,5 mm² 1 EL02515
19 Nozzle housing, 16 pole 1 EST0542
20 Bolt insert, 16 pole 1 EST0543
21 HKL-screwing Pg 16/15 2 EVH1615
22 Housing for control 1 2115041
23 Holder for heating element 1 211501
24 Cover plate 1 211507
22.11.2005 Working instructions WIDOS 4900 CNC 3.0 (110V) Page 73 of 76
