WIKA operating instructions model A2G-50
40202780.03 07/2017 EN/DE
13
DANGER!
Danger to life caused by electric current
Upon contact with live parts, there is a direct danger to life.
▶
The instrument may only be installed and mounted by
skilled personnel.
▶
Operation using a defective power supply unit (e.g. short
circuit from the mains voltage to the output voltage) can
result in life-threatening voltages at the instrument!
1. Instrument xing at the desired mounting location
(see chapter 5.1 “Instrument mounting”)
2. Opening the instrument cover, feeding the connection cable through
the cable gland and connecting the wires to the terminal block (see
chapter 5.2 “Electrical mounting”)
3. The instrument is now ready for conguration (see chapter 5.3
“Conguration”)
