40202780.03 07/2017 EN/DE

14 WIKA operating instructions model A2G-50

5.1 Instrument mounting

Screw the dierential pressure transmitter onto a suitable vertical

surface and x it horizontally with the mounting screws delivered with the

instrument.

1. Select a mounting location (duct, wall, panel).

2. Remove the case cover and use the screw holes as a template.

3. Mount with suitable screws.

5. Commissioning, operation

Instrument xing

Instrument orientation
