WIKA operating instructions model A2G-50
40202780.03 07/2017 EN/DE
21
5. Commissioning, operation
5.6 Setting the response time
The response time aects how fast the transmitter reacts to changes
in the pressure conditions in the system. The response time denes
the time the measuring instrument needs in order to reach 63 % of
the measured value. For unstable pressure conditions, select a longer
response time.
Example:
Selected response time: 4.0 seconds
Result: The output signal reaches a new value in 20 seconds (response
time * 5)
In order to change the response time, install or remove a jumper in slot J4.
■
Jumper in slot J4 - 4.0 seconds response time.
■
No jumper in slot J4 = 0.8 seconds response time
