6. Operation via menu functions
6. Operation via menu functions
6.1 Short overview of menu functions
▶
Press the [MENU/◀▶] button to start.
▶
One accesses the next menu level via the [MENU/◀▶] button.
▶
The [MENU/◀▶] button takes you back one menu level.
If the button is pressed for longer, the cursor turns right “◀” or “▶” left after
2 seconds.
If the arrow points to the left “◀”, you can jump back one menu level by pressing the
[MENU/◀▶] button again.
▶
The [LIGHT/▼] or [ZERO/▲] buttons are used to select the parameters or the menu
levels.
▶
Confirm the selection with the [MENU/◀▶] button.
Menu level 1 Menu level 2 Menu level 3
Measuring mode
Unit
bar (presetting)
mbar
psi
kg/cm²
Pa
kPa
hPa
MPa
mmH₂O
mH₂O
inH₂O
inH₂O (4 °C)
inH₂O (60 °F)
inH₂O (20 °C)
ftH₂O
mmHg
cmHg
inHg
inHg (0 °C)
inHg (60 °F)
kp/cm²
lbf/ft²
