6. Operation via menu functions
Flash interval
■
1 second on
■
0.5 seconds off
In order to activate or deactivate the Alarm function or to change the alarm limits,
proceed as follows under “Menu” / “Measure mode” / “Alarm”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired function.
2. Confirm the selection with the [MENU/◀▶] button.
⇒
With ON or OFF, the instrument moves back one menu level.
⇒
If UPPER or LOWER is selected, an input field appears for the limit value.
⇒
The entry is made from left to right.
3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the number and sign and
use the [MENU/◀▶] button to jump one digit to the right.
4. To accept the set alarm value, press the [MENU/◀▶] button repeatedly until the
instrument jumps back one menu level.
5. Press the [HOME] button in order to exit the menu.
The preset alarm limits are always the measuring range limits ±3 %.
The maximum input value of the alarm limit is ±5 % of the measuring range limit.
Example:
Measuring range 0 … 10 bar
Lower alarm value: -0.3 bar
Upper alarm value: 10.3 bar
The last selected (alarm, peak values or temperature) is always displayed
in the secondary display (matrix field). The previously active will
automatically be deactivated.
Resolution and unit are identical to the main display.
6.2.11 Level
If the Level function is activated, the level units appear under the selectable units. In this
menu item, the density of the medium can be specified in the selected unit.
p = rho * h * g
g = 9.81 m/s²
The preset value for density is always 1.00000 kg/dm³.
If the density unit is changed, the value is automatically converted.
