39WIKA operating instructions, model CPG1500
EN
14161966.06 03/2024 EN/DE
6. Operation via menu functions
In order to activate or deactivate the Level function or to change the calculation factor,
proceed as follows under “Menu” / “Measure mode” / “Level”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired action.
2. Confirm the selection with the [MENU/◀▶] button.
⇒
With ON or OFF, the instrument moves back one menu level.
⇒
If Density is selected, an input field for the calculation factor appears.
⇒
The entry is made from left to right.
3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the number and use the
[MENU/◀▶] button to jump one digit to the right.
4. To accept the set calculation factor, press the [MENU/◀▶] button repeatedly until
the instrument jumps back one menu level.
5. Press the [HOME] button in order to exit the menu.
The input can be aborted with the [HOME] button. The instrument exits
the menu and returns to the main display.
6.2.12 Adjustment
Under Adjustment, the characteristic curve can be shifted by an offset value or a factor
related to the span.
The default settings are:
Offset: 0.0000 Limited to ±5 %
Span.Factor: 1.00000 Limited to ±10 %
In order to make an adjustment of the zero point or the span, proceed as follows under
“Menu” / “Measure mode” / “Adjustment”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired action.
2. Confirm the selection with the [MENU/◀▶] button.
⇒
An input field, Correction factor, appears.
⇒
The entry is made from left to right.
3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the number and use the
[MENU/◀▶] button to jump one digit to the right.
The input can be aborted with the [HOME] button. The instrument exits
the menu, the input is not adopted.
4. To accept the set correction factor, press the [MENU/◀▶] button repeatedly until the
instrument jumps back one menu level.
5. Press the [HOME] button in order to exit the menu.
