66 WIKA operating instructions, model CPG1500
EN
14161966.06 03/2024 EN/DE
Measuring ranges, gauge pressure
bar
0 ... 0.1 0 ... 200
0 ... 0.25 0 ... 250
0 ... 0.4 0 ... 400
0 ... 0.6 0 ... 600
0 ... 1 0 ... 700
1)
0 ... 1.6 0 ... 1,000
1)
0 ... 2.5 0 ... 1,600
1)
0 ... 4 0 ... 2,500
1)
0 ... 6 0 ... 4,000
1)
0 ... 10 0 ... 5,000
1)
0 ... 16 0 ... 6,000
1)
0 ... 25 0 ... 7,000
1) 2)
0 ... 40 0 ... 8,000
1) 2)
0 ... 60 0 ... 9,000
1) 2)
0 ... 100 0 ... 10,000
1) 2)
0 ... 160
1) Not possible as flush design > 600 bar [10,000 psi]
2) Measuring range not possible with CSA approval.
Measuring ranges, absolute pressure
bar abs.
0 ... 0.25 0 ... 6
0 ... 0.4 0 ... 7
0 ... 0.6 0 ... 10
0 ... 1 0 ... 16
0 ... 1.6 0 ... 20
0 ... 2.5 0 ... 25
0 ... 4 0 ... 40
psi
0 ... 5 0 ... 2,000
0 ... 10 0 ... 3,000
0 ... 15 0 ... 5,000
0 ... 20 0 ... 6,000
0 ... 30 0 ... 8,000
0 ... 50 0 ... 10,000
1)
0 ... 60 0 ... 15,000
1)
0 ... 100 0 ... 20,000
1)
0 ... 150 0 ... 30,000
1)
0 ... 160 0 ... 40,000
1)
0 ... 200 0 ... 50,000
1)
0 ... 300 0 ... 60,000
1)
0 ... 500 0 ... 75,000
1)
0 ... 700 0 ... 100,000
1) 2)
0 ... 1,000 0 ... 150,000
1) 2)
0 ... 1,500
psi abs.
0 ... 3.5 0 ... 60
0 ... 5 0 ... 100
0 ... 10 0 ... 150
0 ... 15 0 ... 200
0 ... 20 0 ... 300
0 ... 30 0 ... 500
0 ... 50
10. Specifications
