67WIKA operating instructions, model CPG1500
EN
14161966.06 03/2024 EN/DE
Measuring ranges, vacuum and +/- measuring ranges
bar
-0.25 ... +0.25 -1 ... 7
-0.4 ... +0.4 -1 ... 9
-0.6 ... +0.6 -1 ... 10
-1 ... 0 -1 ... 15
-1 ... +0.6 -1 ... 24
-1 ... 1.5 -1 ... 25
-1 ... 2.5 -1 ... 39
-1 ... 3 -1 ... 40
-1 ... 5
Other measuring ranges on request.
Further details on: measuring ranges
Overpressure limit
3 times < 25 bar < 360 psi
2 times > 25 ... ≤ 600 bar > 360 ... ≤ 8,700 psi
1.5 times > 600 ... ≤ 1,600 bar > 8,700 ... ≤ 25,000 psi
1.3 times > 1,600 ... ≤ 6,000 bar > 25,000 ... ≤ 85,000 psi
1.1 times > 6,000 bar > 85,000 psi
Indication > 110 % FS or -10 % FS
Vacuum resistance Ye s
Process connection
Standard Thread sizes Possible measuring ranges
EN 837
■
G ¼ B
■
G ½ B
■
G ⅜ B
■
G ¼, female thread
≤ 1,000 bar [≤ 15,000 psi]
G ½ B flush with O-ring
(NBR)
2.5 ... 600 bar [50 ... 6,000 psi]
G 1 B flush with O-ring
(NBR)
0.4 ... 16 bar [10 ... 200 psi]
psi
-14.5 ... 0 -8 ... +8
-14.5 ... +15 -5 ... +5
-14.5 ... 40 -3 ... +3
-14.5 ... 70 -8 ... 0
-14.5 ... 100 -5 ... 0
-14.5 ... 130 -3 ... 0
-14.5 ... 300
10. Specifications
