68 WIKA operating instructions, model CPG1500
EN
14161966.06 03/2024 EN/DE
Process connection
Standard Thread sizes Possible measuring ranges
ANSI/ASME
B1.20.1
■
½ NPT
■
¼ NPT
■
½ NPT, female thread
■
¼ NPT, female thread
■
½ NPT, male thread
≤ 1,000 bar [≤ 15,000 psi]
DIN 16288 M20 x 1.5 ≤ 1,000 bar [≤ 15,000 psi]
ISO 7 (DIN 2999) R ½ ≤ 1,000 bar [≤ 15,000 psi]
DIN EN ISO 1179-2 G ½, male thread on G ⅛,
female thread
≤ 400 bar [≤ 5,800 psi]
- M16 x 1.5, female thread,
with sealing cone
≥ 100 bar [≥ 1,500 psi]
M20 x 1.5, female thread,
with sealing cone
1,600 ... 10,000 bar
[30,000 ... 150,000 psi]
9/16-18 UNF, female
thread F 250-C
100 ... 7,000 bar
[1,500 ... 100,000 psi]
→ For drawings of process connections, see chapter 10.5.3 “Process connections”.
Further details on: process connection
Process connection adapter
1)
■
Without
■
G ½ to ¼ NPT
■
G ½ to ½ NPT
Sealing
■
NBR
■
EPDM
Other versions
Oil- and grease-free Per G93:2019 level D (< 220 mg/m²)
Oxygen, oil- and grease-free
■
Per G93:2019 level D (< 220 mg/m²)
■
Particle < 1,000 μm
Material
Case Aluminium die-casting, nickel-plated
Wetted parts -1 ... < 40 bar
[-14.5 ... < 500 psi]
Stainless steel 1.4404 (316L)
> 40 bar ... ≤ 1,000 bar
[> 500 ... ≤ 15,000 psi]
■
Process connection:
Stainless steel 1.4404
(316L)
■
Sensor: Elgiloy
®
2.4711
> 1,000 bar [>15,000 psi] Stainless steel 1.4534 (904L)
10. Specifications
